Key Attributes:
| Model Number : | JT-RA3 | Model Name : | Full-automatic Servo-driven Three-colors Screen Printing Machine |
| Application : | For The Glass Industry, For The Plastics Industry | Brand name ; | JT (LH) |
| Printing product shape : | Round container | Oval container | Special-shape bottle |
| Max. printing arrange(mm) : | Perimeter :315mm; Height :200mm | Perimeter :315mm; Height :200mm | Perimeter :315mm; Height :200mm |
| Printing product dimensions(mm) : | Height :30-330mm; Dia. :Φ15-Φ100 | Height :30-330mm; Product Max. rotating diameter :100mm | Height :30-330mm; Product Max. rotating diameter :100mm |
| Speed (pcs/min) : | 40-50 | 30-40 | 25-40 Double side-flat printed：25-35 |
| AC Power : | AC380V 3phase 50/60HZ | Electric power : | 26KW |
| Compress air : | Air pressure(bar) :5-7bar Air flow value(L/min) :200 (L/min) | Grade : | Automatic |
| Machine size : | 3100*3000*2160mm | Machine weight : | 5100 kgs |
| Main Configuration : | Servo Motor | Servo Drive | Vision System |
Application Scope：
This machine is suitable for packaging of glass products, packaging materials, cosmetic packaging, acrylic products, daily chemical products, washing and care products, wine bottle packaging, reagent bottles and food outer packaging containers. The applicable materials include glass, plastic, resin, acrylic, ceramics, metal, etc.
Our Service
Pre Sale：
1,We provide sample testing support.
2,Provide professional advice to provide customers with the best solution.
3,According to the customer's needs or requirements, our engineers will povide you with drawings and solutions.
4,We will provide competitive prices based on customer solutions.
5,Before shipping ,we will provide product testing videos and pictures for customer confirm before shipping.
After Sale:
1,We will send engineers to the site for installation, debugging , and operation training.
2,We will provide fault handing services and lifetime warranty.
3,We provide a 5 years warranty for each machine.
4,We will contact you regularly to understand the condition of the machine.
5,We also offer services to further expand on your existing machine.
